Small substrate type Three-output power supply CUT-J series has added a double-sided substrate coating option

2019-08-23 | Return

Substrate double-sided coating option (/ CO2) is added to TDK-Lambda brand board type three output AC-DC power supplies CUT35J and CUT75J, and orders start from August 23.

Main uses

Industrial / commercial automatic equipment, measuring equipment, semiconductor manufacturing equipment, medical equipment, etc.

Key features and benefits

Low profile, small size, industry standard size (CUT35J: 2 x 4 inches, CUT75J: 3 x 5 inches)

No minimum load current required for each channel

Wide operating temperature range: -20 to + 70 ° C (CUT35J: up to + 55 ° C, CUT75J: 100% load up to + 50 ° C)

* CUT-J series option lineup ★: New addition ●: Existing

/ A: With cover / L: CUT35J with L sheet metal / CUT75J with U sheet metal
/ B: With base plate / T: European terminal specification (screw type) / CO2: Double-sided coating specification
* CH2 and CH3 are connected in series Therefore, it can be used as a dual output power supply.
