THE SCHAFFNER GROUP INTRODUCES ECOSINE® MAX SERIES OF PASSIVE HARMONIC FILTERS

2020-03-24 | Return

Schaffner, the international leader in the fields of electromagnetic compatibility and power quality, is pleased to announce its new ecosine® max passive harmonic filter series. These new filters are designed to reliably mitigate excessive harmonics in most demanding applications.

The new ecosine® max filter series FN3470/71, FN3480/81, FN3472/73 and FN3482/83 with versions for 400 VAC and 480 VAC, 50 Hz and 60 Hz networks are based on Schaffner award-winning ecosine® platform. They are the key passive power quality offer for higher power ranges (250KW-500KW) that can be found in demanding drive applications. The three-chokes versions FN3470/80/72/82 are designed to achieve <5% THDi @ rated power even when using drives without DC-link choke. The more economical two-chokes versions FN3471/81/73/83 are designed to achieve <5% THDi @ rated power if used with drives including at least 4% DC-link choke. They can also be applied to drives without DC-link choke reaching a THDi of 8%.

The industry’s most advanced passive harmonic filter ecosine® max guarantee compliance with the requirements of IEEE-519 and other stringent national or international power quality standards. While using ecosine® max filters the electrical infrastructure is unburdened, and its utilization is much more efficient and reliable. Furthermore, the service life cycle of electrical equipment is extended, and energy costs can be reduced.

As Schaffner is always committed to customer satisfaction, innovation and continuous improvement is of importance. Schaffner Power Quality always aims for best tailored solutions aligning product offerings with the international market requirements and customer expectations. Being the industry standard filters for 6-pulse rectifiers and motor drives ecosine® max filter series are designed to be the most compact open panel solutions that are ready to be integrated in standard or customized electrical cabinets. All ecosine® max filters are CE-marked, UL listed and RoHS compliant.

All versions are offered either with a circuit breaker switch protecting the trap capacitor bank or with a trap disconnect jumper to allow any third-party circuit breaker switch to be installed. This protection ensures the operational safety of the device even under all circumstances.

Schaffner power quality is more than just products. We provide solutions for power efficiency and reliability along with leading pre- and after sales services. Therefore all ecosine® max filter series, like all Schaffner active and passive harmonic filters, are already fully supported in Schaffner’s well known power quality simulator SchaffnerPQS3.

Source：http://www.schaffner.com/
