Johanson Technology announces the release of part 8000BP14A0500001T, a high-performance Ultra-Wideband (UWB) Channel 9 Band Pass Filter designed for applications demanding stringent bandwidth and signal integrity requirements. This device is engineered to operate within the frequency range of 7737 - 8237 MHz, providing excellent selectivity and minimal interference, making it ideal for high-speed wireless communication systems.

This LTCC filter operates efficiently in the UWB CH 9 pass band of 7737 - 8237 MHz, making it suitable for applications such as real-time location systems (RTLS), secure access control, contactless payment systems, secure data transfer, smart sensor networks and enhanced navigation systems. Designed to be compatible with UWB chipset vendor reference designs, including Qorvo’s QM35720, it is an ideal choice for a wide range of UWB products.

This UWB Band Pass Filter manages up to 3W maximum power with a maximum insertion loss of 1.65 dB and a minimum return loss of 12 dB over the operating frequency, accommodating robust performance demands. An SMD EIA 0603 case size (1.6 x 0.8 x 0.6 mm) makes the 8000BP14A0500001T an optimal solution for space-constrained applications. This part is also RoHS compliant, ensuring environmental safety and global acceptance.

Explore our detailed filter datasheets with comprehensive specifications, and request samples using the link below.

Engage with a Johanson RF Engineer or connect with a local sales representative to receive personalized guidance and support tailored to your needs.

Available for sampling, and mass production quantities!
