Toshiba Introduces Lens Reduction Type CCD Linear Image Sensor for A3 Multifunction Printers

2021-03-17 | Return
TOKYO—Toshiba Electronic Devices & Storage Corporation ("Toshiba") has launched “TCD2726DG,” a lens reduction type CCD linear image sensor that achieves high-speed scanning for A3multifunction printers. Shipments of engineering samples[1] start today.

There is growing demand for A3 multifunction printers with higher scanning speeds. TCD2726DG meets the demand by improving the performance with a faster operating clock rate: a 100MHZ (50MHz x 2ch) data rate, against the 70MHz (35MHz x 2ch) data rate of Toshiba’s current sensor[2].

To prevent increased electromagnetic interference (EMI), a negative side effect of a faster clock rate, the new sensor incorporates a timing generator circuit and has a lower CCD driver pin count. This reduces EMI- and timing-adjustment work for customers, and the number of peripheral parts, contributing to easier system development.

[1] The samples are for functional evaluation. Their specifications may differ from those for mass production.
[2] TCD2724DG-1

Key Features

> 100MHz (50MHz x 2ch) data rate, CCD linear image sensor
> Built-in Timing Generator circuit and CCD driver, facilitating system development
> Low power consumption: 10V power supply voltage for amplifier circuit lowered to 3.3V[3]

[3] 10V power supply is used partially. Dual power supply of 3.3V and 10V.

Applications

A3 multifunction printers, automated optical inspection equipment

Main Specifications

Part number

TCD2726DG

Power Supply voltage (operating range)

AVDD, DVDD, CKDVDD : 3.1 V to 3.5 V

VDD10 : 9.5 V to 10.5 V

Pixel size

4.7 μm

Number of image sensing elements

7500 elements by 3 lines

Data rate

100MHz (50MHz×2ch)

Package

WDIP32Size: 53.60 mm×9.65 mm

Others / Additional features

Timing Generator circuit

CCD driver


For more information about the new product, visit:

TCD2726DG

For more information about Toshiba’s linear image sensor line-up, visit:

Linear Image Sensors
